Standard handling systems from Festo’s multi-axis modular system
Pick & place
Cantilever axis combined with
slide or additional cantilever
axis for Z-movement.
For applications where the grip-
per unit needs to be retracted
from the area of activity.
• Can be combined with a slide
or additional cantilever axis
along the Z-axis
• High mechanical rigidity, stur-
dy design
• Pneumatic and electrical com-
ponents – freely combinable
Linear gantries
Gantry axis combined with
slides or cantilever axes for
Z-movement.
Rugged, for long gantry strokes
combined with heavy loads.
• Can be combined with a slide
or cantilever axis along the
Z-axis
• High mechanical rigidity and
sturdy design
• Pneumatic and electrical com-
ponents – freely combinable
Cantilever
Two parallel gantry axes plus
pick & place with short Z-stroke,
preferably with slide.
Ideal for applications where
three-dimensional gantries are
too big or interfere with the area
of activity.
• Short Z-stroke, preferably with
mini slide
• Sturdy design
• Pneumatic and electrical com-
ponents – freely combinable
Three-dimensional gantries
Two gantry axes plus an addi-
tional gantry axis arranged
transversely, as well as a drive
for Z-movement. For any move-
ment in 3D space - extremely
precise and very sturdy for high
loads and long strokes.
• High mechanical rigidity
• Universal in use, including for
very heavy workpieces and
high effective loads
• Dynamic, precise, powerful -
depending on axis selection.
• Pneumatic and electrical com-
ponents – freely combinable
