BionicSwift Agile wing beat based on a natural role model 02: Artificial plumage: shingle-like ar- rangement of the individual lamellae 06: Aerodynamic kinematics: torsional capacity of the wings 03: Quiet wing beat: lamellae made of light foam 01: Coordinated flying: flying in forma- tion in a confined airspace 05: Intelligent navigation: master com- puter, radio module and flying objects interact with each other 04: Agile flying object: agile manoeuvres such as loops and tight turns The flight of birds has always fascinated humankind. In Festo’s Bionic Learning Network, flying according to the natural world also has a long tradition. With the construction of the BionicSwifts, Festo is consistently continuing the further development of its bionic flying objects. Ultralight flying objects When designing the artificial birds, the focus was on the use of lightweight structures, just like their biological role model. Be- cause the same applies in engineering as it does in nature: the less weight there is to move, the lower the use of materials and energy consumption. And so, with a body length of 44.5 centi- metres and a wingspan of 68 centimetres, each of the bionic birds weighs just 42 grams. The BionicSwifts are therefore very agile, nimble and can even fly loops and tight turns. By interacting with a radio-based indoor navigation system with ultra wideband technology (UWB), the robotic birds can move in a coordinated and autonomous manner within a defined airspace. Aerodynamic plumage for efficient flight To execute these flight manoeuvres as true to life as possible, the wings are modelled on the plumage of real birds. The individual lamellae are made of an ultralight, flexible but very robust foam and lie on top of each other like shingles. Connected to a carbon quill, they are attached to the actual hand and arm wings as in the natural model. During the wing upstroke, the individual lamellae fan out so that air can flow through the wing. This means that the birds need less force to pull the wing up. During the downstroke, the lamellae close up so that the birds can generate more power to fly. Due to this close-to-nature replica of the wings, the BionicSwifts have a better flight profile than previous wing-beating drives. Functional integration in the tightest of spaces The artificial birds owe their agility not only to their lightweight construction and aerodynamic kinematics, but also to the system- atic approach to functional integration. The bird’s body contains the compact construction for the wing- flapping mechanism, the communication technology, the control components for wing flapping and the elevator, the tail. A brush- less motor, two servomotors, the battery, the gearbox and various circuit boards are installed in a very small space. The intelligent interaction of motors and mechanics allows, for example, the frequency of the wing beat and the elevator’s angle of attack to be precisely adjusted for the various manoeuvres. Coordination of flight manoeuvres by GPS Radio-based indoor GPS with ultra wideband technology (UWB) enables the coordinated and safe flying of the BionicSwifts. For this purpose, several radio modules are installed in one room. These anchors then locate each other and define the controlled airspace. Each robotic bird is also equipped with a radio marker. This sends signals to the anchors, which can then locate the exact position of the bird and send the collected data to a central master computer which acts as a navigation system. This can be used for route planning, so that preprogrammed routes give the birds their flight path. If the birds deviate from their flight path due to sudden changes in environmental influences such as wind or thermals, they immediately correct their flight path them- selves and intervene autonomously in this situation – without a human pilot. Radio communication enables exact position detec- tion even if visual contact is partially hindered by obstacles. The use of ultra wideband as radio technology guarantees safe and trouble-free operation. New impetus for intralogistics The intelligent networking of flight objects and GPS routing makes for a 3D navigation system that could be used in the networked factory of the future. The precise localisation of the flow of mater- ials and goods could, for example, improve process sequences and foresee bottlenecks. Moreover, autonomous flying robots could be used to transport materials, for instance, and thus optimise the use of space within a factory with their flight corridors. 02 03 01 04 05 06 2 Festo SE & Co. KG 3 BionicSwift: Safe aerial acrobatics as a swarm
