Asnugfit:
IPTE concentrates theentiresolderingprocess
in thesmallest of spaces.
All inone:
mechanical components, servomotors, controllers,
compressedair preparationandvalve terminals from Festo.
IPTEFactory
Automationn.v.
Geleenlaan5
3600Genk
Belgium
Areaof business:
Development of turnkeyautomation
solutions for theproduction, testing
and further processingof printed
circuit boardassembliesandend
products
crashsensor protects theboardsagainst
excessivepressure.
Custommadeand completepackage
IPTEdesigned theXYZW-gantrysystem
with four degreesof freedom,with
support from Festoduring thedesignand
productionprocess. TheX-, Y- andZ-axes
usestandardspindleand toothedbelt
drivesof the typeEGCandEGCwith
integrateddisplacement encoder and
mini slideEGSL. For the rotaryunit
(W-axis), Festodevelopeda custommade
module. Thegantry for flexibleand
controlledspeedandacceleration (XYZ-
axis) anda rotarymoduleERMBwere
speciallyadapted to thesystemandare
used for liftingand rotating thesoldering
needle. Thismeans that thesystem can
reachevendifficult toaccess locations in
thesensor housing, andsolder at
precisely the right anglewith the right
force. It is capableofhighspeed
positioning, despite thehighmoving
mass.
Guaranteedmore reliability
IPTE’snewmachine concept canbeused
anywhere. Apart fromsoldering
applications, it canalsobeused formany
other taskssuchasdispensing.Thegantry,
which includesservomotorsand
controllersof the typeCMMPwith
EtherCat interface, isadaptedby Festo to
thespecific requirementsof thedifferent
applicationsandsuppliedasa ready-to-
install completesystem. Festoprovides
anadditional level of reliabilityby
guaranteeing the functionof thesystem
ondelivery. The customer not only
receivesa ready-to-install handling
system, hecanalsobesure that itwill
functionproperly right from thestart.
